Model: Elemetar Analysensysteme GmbH, Germany
Make: Unicube
Description:
Applications:
| In this analyzer, Carbon, Hydrogen, Nitrogen, Sulfur and Oxygen analysis is based on High temperature combustion or pyrolysis of the sample and conversion of the elements into gaseous products. Separation of gases by direct temperature programmed desorption column and detection by TCD. |
| Percentage Concentration of C, H, N, S, O in samples from R & D labs, Quality control labs, academic research groups from pharma, herbal, chemical, paint, food, soil, drug catalyst, etc., can be analysed. |
| Provides solution for the elemental analysis of Organic compounds, Pharmaceuticals, Petrochemicals, Gasoline & Flues, Coal &Coke, Graphite, Carbides & Nitrides, Polymers. |
| Agriculture Products-Plants and leaves, Wood, Food products & Dairy products can be analysed . |
Specifications:
| Five elements- C, H, N, S, O analysis in a single instrument | Operating Modes: CHNS, O |
| High temperature (up to 1200°C) combustion furnace | Robust TCD detector |
| Temperature Programmed Desorption (TPD) column (Patented). | Typical analysis time of 7-10 min per sample for CHNSO. |
| Solid and liquid both sample forms can be analysed. | Accuracy: 0.3% abs |
| Sample Size: 1 to 50 mg |
